2004-2019 Yamaha YFZ450 13.5:1 95mm std bore platinum series 1mm smaller pin/ 3.5mm long rod, profiled pin bore pro race piston kit
- Bore: 95mm
- Comp Ratio: 13.25:1 439cc; 13.5:1 449cc
- Piston #: MX1P26-P
- CPK #: YFZ450 CPKX1P26-P; YFZ450R CPKX1P26R-P
- Rod #: 04-05 6130; 06-07 6129 09-18 8802
- Pin #: S748-2000-15C
- Locks #: 748x050 SWL
- Rings #: CP9500C
- Gasket Only #: YFZ450 C3066; YFZ450R C7908
2004-2019 Yamaha YFZ450 13.5:1 95mm std bore platinum series 1mm smaller pin/ 3.5mm long rod piston kit
- Bore: 95mm
- Comp Ratio: 13.25:1 439cc; 13.5:1 449cc
- Piston #: MX1P26
- CPK #: YFZ450 CPKX1P26; YFZ450R CPKX1P26R
- Rod #: 04-05 6130; 06-07 6129 09-18 8802
- Pin #: S748-2000-15C
- Locks #: 748x050 SWL
- Rings #: CPN2-2-3740
- Gasket Only #: YFZ450 C3066; YFZ450R C7908
2004-2019 Yamaha YFZ 450 13.5:1 95mm std bore profiled pin bore pro race piston kit
- Bore: 95mm
- Comp Ratio: 13.25:1 439cc; 13.5:1 449cc
- Piston #: MX1026-P
- CPK #: YFZ450 CPKX1026-P; YFZ450R CPKX1126-P
- Rod #: 04-05 9660 06-08 custom; 09-15 8808
- Pin #: S787-2000-15C
- Locks #: 787x050 SWL
- Rings #: CPN2-2-3740
- Gasket Only #: YFZ450 C3066; YFZ450R C7908
2004-2019 Yamaha YFZ450/R Race 13.5:1 95mm std bore piston kit
- Bore: 95mm
- Comp Ratio: 13.25:1 439cc; 13.5:1 449cc
- Piston #: MX1026
- CPK #: YFZ450 CPKX1026; YFZ450R CPKX1126
- Rod #: 04-05 9660 06-08 custom; 09-15 8808
- Pin #: S787-2000-15C
- Locks #: 787x050 SWL
- Rings #: CPN2-2-3740
- Gasket Only #: YFZ450 C3066; YFZ450R C7908
2004 -2019 Yamaha YFZ450/R 11.8:1 :1 95mm std bore piston kit
- Bore: 95mm
- Comp Ratio: 11.8:1 439cc; 12.1:1 449cc
- Piston #: M1100
- CPK #: CPK1100
- Rod #: 04-05 9660; 06-08 custom 09-15 8808
- Pin #: 787-2000-15CP1C
- Locks #: 787x050 SWL
- Rings #: CPN2-3740
- Gasket Only #: YFZ450 C3066; YFZ450R C7908
2004-2019 Yamaha YFZ 450 13.75:1 98mm +3mm oversize bore piston kit
- Bore: 98mm
- Comp Ratio: 13.5:1 468cc; 13.75:1 478cc
- Piston #: M1085
- CPK #: CPK1085
- Rod #: 04-05 9660 06-08 custom; 09-15 8808
- Pin #: W787-2000-15CP1C
- Locks #: 787x050 SWL
- Rings #: CPN2-3858
- Gasket Only #: YFZ450 C3068; YFZ450R C3178
2004 -2019 Yamaha YFZ450/R 12.75:1 95mm std bore piston kit
- Bore: 95mm
- Comp Ratio: 12.5:1 439cc; 12.75:1 449cc
- Piston #: M1000
- CPK #: CPK1000
- Rod #: 04-05 9660; 06-08 custom 09-15 8808
- Pin #: W787-2000-15CP1C
- Locks #: 787x050 SWL
- Rings #: CPN2-3740
- Gasket Only #: YFZ450 C3066; YFZ450R C7908
2004-2019 Yamaha YFZ450/R 13.25:1 95mm std bore piston kit
- Bore: 95mm
- Comp Ratio: 13.0:1 439cc; 13.25:1 449cc
- Piston #: M1001
- CPK #: CPK1001
- Rod #: 04-05 9660 06-08 custom; 09-15 8808
- Pin #: W787-2000-15CP1C
- Locks #: 787x050 SWL
- Rings #: CPN2-3740
- Gasket Only #: YFZ450 C3066; YFZ450R C7908
2004-2019 Yamaha YFZ 450/R 13.75:1 95mm standard bore piston kit
- Bore: 95mm
- Comp Ratio: 13.25:1 439cc; 13.5:1 449cc
- Piston #: M1002
- CPK #: CPK1002
- Rod #: 04-05 9660 06-08 custom; 09-15 8808
- Pin #: W787-2000-15CP1C
- Locks #: 787x050 SWL
- Rings #: CPN2-3740
- Gasket Only #: YFZ450 C3066; YFZ450R C7908
2004-2019 Yamaha YFZ450/R 12.75:1, 98mm +3mm oversize piston kit
- Bore: 98mm
- Comp Ratio: 12.5:1 468cc; 12.75:1 478cc
- Piston #: M1009
- CPK #: CPK1009
- Rod #: 04-05 9660 06-08 custom; 09-15 8808
- Pin #: W787-2000-15CP1C
- Locks #: 787x050 SWL
- Rings #: CPN2-3858
- Gasket Only #: YFZ450 C3068; YFZ450R C3178
2004-2019 Yamaha YFZ450/R 13.75:1 97mm +2mm oversize bore Piston Kit
- Bore: 97mm
- Comp Ratio: 13.5:1 458cc; 13.75:1 468cc
- Piston #: M1008
- CPK #: CPK1008
- Rod #: 04-05 9660 06-08 custom; 09-15 8808
- Pin #: W787-2000-15CP1C
- Locks #: 787x050 SWL
- Rings #: CPN2-3819
- Gasket Only #: YFZ450 C3068; YFZ450R C3178
2004- 2019 Yamaha YFZ450/R 12.75:1 97mm +2mm oversize bore piston kit
- Bore: 97mm
- Comp Ratio: 12.5:1 458cc; 12.75:1 468cc
- Piston #: M1006
- CPK #: CPK1006
- Rod #: 04-05 9660 06-08 custom; 09-15 8808
- Pin #: W787-2000-15CP1C
- Locks #: 787x050 SWL
- Rings #: CPN2-3819
- Gasket Only #: YFZ450 C3068; YFZ450R C3178
2004-2019 Yamaha YFZ450/R 13.25:1 97mm +2mm oversize bore piston kit
- Bore: 97mm
- Comp Ratio: 13.0:1 458cc; 13.25:1 468cc
- Piston #: M1007
- CPK #: CPK1007
- Rod #: 04-05 9660 06-08 custom; 09-15 8808
- Pin #: W787-2000-15CP1C
- Locks #: 787x050 SWL
- Rings #: CPN2-3819
- Gasket Only #: YFZ450 C3068; YFZ450R C3178
2005 KTM 450XC 13.0:1 89mm std bore x 72mm stroke (447.92cc), piston kit
- Bore: 89mm
- Comp Ratio: 13.0:1
- Piston #: M9009
- CPK #: CPK9009
- Rod #: 5418
- Pin #: W787-2000-15CP1C
- Locks #: 787x050 SWL
- Rings #: CPN2-2-3504
- Gasket Only #: C3263
2005 KTM 450XC 12.0:1 89mm std bore x 72mm stroke (447.92cc), piston kit
- Bore: 89mm
- Comp Ratio: 12.0:1
- Piston #: M9008
- CPK #: CPK9008
- Rod #: 5418
- Pin #: W787-2000-15CP1C
- Locks #: 787x050 SWL
- Rings #: CPN2-2-3504
- Gasket Only #: C3263
2005-2007 Suzuki KingQuad 700 11.5:1 102mm std bore x 85mm stroke (695cc) piston kit
- Bore: 102mm
- Comp Ratio: 11.5:1
- Piston #: M4013A
- CPK #: CPK4013A
- Rod #: N/A
- Pin #: W905-2250-15CP1C
- Locks #: 905X073 SWL
- Rings #: CPN-4016
- Gasket Only #: C3128
2005-2007 Suzuki King Quad 700 11.5:1 104mm +2mm oversize bore x 85mm stroke piston kit
- Bore: 104mm
- Comp Ratio: 11.5:1
- Piston #: M4051
- CPK #: CPK4051
- Rod #: N/A
- Pin #: W905-2250-15CP1C
- Locks #: 905X073 SWL
- Rings #: RS1318-4090-5THG
- Gasket Only #: C3128
2005-2007 Suzuki King Quad 700 12.5:1 106mm +4mm oversize bore x 85mm stroke piston kit
- Bore: 106mm
- Comp Ratio: 12.5:1
- Piston #: M4022
- CPK #: CPK4022
- Rod #: N/A
- Pin #: W905-2250-15CP1C
- Locks #: 905X073 SWL
- Rings #: RS1000NCR-4170-0
- Gasket Only #: C3128
2005-2007 Suzuki King Quad 700 11.5:1 106mm +4mm oversize bore x 85mm stroke piston kit
- Bore: 106mm
- Comp Ratio: 11.5:1
- Piston #: M4014
- CPK #: CPK4014
- Rod #: N/A
- Pin #: W905-2250-15CP1C
- Locks #: 905X073 SWL
- Rings #: 1-S10-4170-5 2-S20-4170-5 3-H30-4170-0NC
- Gasket Only #: C3128
2005-2007 Suzuki RM-Z450 13.5:1 95.5mm std bore x 62.8mm stroke (449cc) piston kit
- Bore: 95.5mm
- Comp Ratio: 13.5:1
- Piston #: MX4009A
- CPK #: CPKX4009A
- Rod #: 8809
- Pin #: S748-2000-15C
- Locks #: 748x050 SWL
- Rings #: CPN2-2-3759
- Gasket Only #: C3102
2005-2007 Suzuki RM-Z 12.5:1 98mm +2.5mm oversize bore x 62.8mm stroke (473cc) piston kit
- Bore: 98mm
- Comp Ratio: 12.5:1
- Piston #: M3005
- CPK #: CPK3005
- Rod #: 8809
- Pin #: W748-2000-15CP1C
- Locks #: 748x050 SWL
- Rings #: CPNZ-3858
- Gasket Only #: C3127
2005-2007 Suzuki RM-Z450 13.0:1 95.5mm std bore x 62.8mm stroke (449cc) piston kit
- Bore: 95.5mm
- Comp Ratio: 13.0:1
- Piston #: M3006A
- CPK #: CPK3006A
- Rod #: 8809
- Pin #: W748-2000-15CP1C
- Locks #: 748x050 SWL
- Rings #: CPN2-2-3759
- Gasket Only #: C3102
2005-2007 Suzuki RM-Z450 13.5:1 95.5mm std bore x 62.8mm stroke (449cc) piston kit
- Bore: 95.5mm
- Comp Ratio: 13.5:1
- Piston #: M4009A
- CPK #: CPK4009A
- Rod #: 8809
- Pin #: W748-2000-15CP1C
- Locks #: 748x050 SWL
- Rings #: CPN2-2-3759
- Gasket Only #: C3102
2005-2008 Suzuki GSXR 1000 12.5:1 76mm +2.6mm oversize bore +4mm stroke std pin location (1142cc) piston kit
- Bore: 76mm
- Comp Ratio: 12.5:1
- Piston #: MX4041C-050 *
- CPK #: CPKX4041C-050
- Rod #: 4722
- Pin #: 591-1650-13CP1C
- Locks #: 591x050 SWL
- Rings #: CP7600C
- Gasket Only #: C8602-28
2005-2008 Suzuki GSXR 1000 13.5:1 76mm +2.6mm oversize bore x 59mm stroke (1078cc) piston kit
- Bore: 76mm
- Comp Ratio: 13.5:1
- Piston #: MX4019C-050
- CPK #: CPKX4019C
- Rod #: 4722
- Pin #: 591-1650-13CP1C
- Locks #: 591x050 SWL
- Rings #: CPXG-7600C
- Gasket Only #: C8602-27
2005-2008 Suzuki GSXR 1000 13.5:1 73.4mm std bore x 59mm stroke piston kit for turbo use 15psi 550 hp
- Bore: 73.4mm
- Comp Ratio: 10.0:1
- Piston #: M4058 **
- CPK #: Call
- Rod #: 4722
- Pin #: 591-2000-14CP1C
- Locks #: 591x050 SWL
- Rings #: MAC07340
- Gasket Only #: Call
2005-2008 Suzuki GSXR 1000 12.0:1 73.4mm std bore x 59mm stroke nitrous 80 shot piston kit
- Bore: 73.4mm
- Comp Ratio: 12.0:1
- Piston #: M4056 ***
- CPK #: Call
- Rod #: 4722
- Pin #: 591-2000-14CP1C
- Locks #: 591x050 SWL
- Rings #: MAC07341
- Gasket Only #: Call
2005-2008 Suzuki GSXR 1000 10.0:1 73.4mm std bore x 59mm stroke piston kit
- Bore: 73.4mm
- Comp Ratio: 13.5:1
- Piston #: M4047
- CPK #: CPK4047
- Rod #: 4722
- Pin #: 591-1500-13CP1C
- Locks #: 591x050 SWL
- Rings #: MAC07340
- Gasket Only #: Call
2005-2008 Suzuki GSXR 1000 13.5:1 75mm +1.6mm oversize bore x 59mm stroke (1043cc) piston kit
- Bore: 75mm
- Comp Ratio: 13.5:1
- Piston #: M4018-050
- CPK #: CPK4018
- Rod #: 4722
- Pin #: 591-1810-11CP3C
- Locks #: 591x050 SWL
- Rings #: CPUG-2953
- Gasket Only #: Call
2005-2013 YZ250F 13.5:1 77mm std bore x 53.6mm stroke (250cc), piston kit
- Bore: 77mm
- Comp Ratio: 13.5:1
- Piston #: MX1034C
- CPK #: CPKX1034C
- Rod #: 8807
- Pin #: S630-1650-13C
- Locks #: 630x050 SWL
- Rings #: CP7700C
- Gasket Only #: C3057
2005-2013 YZ250F 14.0:1 77mm +2mm bore x 53.6mm stroke (250cc) piston kit
- Bore: 77mm
- Comp Ratio: 14.0:1
- Piston #: MX1035C
- CPK #: CPKX1035C
- Rod #: 8807
- Pin #: S630-1650-13C
- Locks #: 630x050 SWL
- Rings #: CP7700C
- Gasket Only #: C3057
2005-2013 YZ250F 12.5:1 79mm +2mm bore x 53.6mm stroke (263cc) piston kit
- Bore: 79mm
- Comp Ratio: 12.5:1
- Piston #: MX1036C
- CPK #: CPKX1036C
- Rod #: 8807
- Pin #: S630-1650-13C
- Locks #: 630x050 SWL
- Rings #: CP7900C
- Gasket Only #: C3057
2005-2013 YZ250F 13.5:1 77mm std bore x 53.6mm stroke (250cc), piston kit
- Bore: 77mm
- Comp Ratio: 13.5:1
- Piston #: M1034C
- CPK #: CPK1034C
- Rod #: 8807
- Pin #: W630-1650-13CP1C
- Locks #: 630x050 SWL
- Rings #: CP7700C
- Gasket Only #: C3057
2005-2013 YZ250F 13.5:1 80mm +3mm bore x 53.6mm stroke (269cc) piston kit
- Bore: 80mm
- Comp Ratio: 13.5:1
- Piston #: MX1050C
- CPK #: CPKX1050C
- Rod #: 8807
- Pin #: S630-1650-13C
- Locks #: 630x050 SWL
- Rings #: CP8000C
- Gasket Only #: C3059
2005-2013 YZ250F 14.25:1 77mm std bore x 53.6mm stroke (250cc) piston kit
- Bore: 77mm
- Comp Ratio: 14.25:1
- Piston #: MX1135C
- CPK #: CPKX1135C
- Rod #: 8807
- Pin #: S630-1650-13C
- Locks #: 630x050 SWL
- Rings #: CP7700C
- Gasket Only #: C3057
2005-2013 Yamaha YZ250F 14.0:1 77mm std bore x 53.6mm stroke platinum series 1mm smaller pin/ 2mm longer rod (250cc) piston kit
- Bore: 77mm
- Comp Ratio: 14.0:1
- Piston #: MX1P35C
- CPK #: CPKX1P35C
- Rod #: 6126
- Pin #: S591-1650-13C
- Locks #: 591x040 SWL
- Rings #: CP7700C
- Gasket Only #: C3057
2005-2015 RXP 215/255/260 9.5:1 turbo, 100.5mm +.5mm oversize bore x 63.4mm stroke (1508cc) piston kit
- Bore: 100.5mm
- Comp Ratio: 9.5:1
- Piston #: M9042
- CPK #: CPK9042
- Rod #: 5476
- Pin #: 905-2250-19CP3C
- Locks #: 905X073 SWL
- Rings #: CPN-3957
- Gasket Only #: H30220305
2005-2015 RXP 215/255/260 8.4:1 turbo 100mm std bore x 63.4mm stroke (1494cc) piston kit
- Bore: 100mm
- Comp Ratio: 8.4:1
- Piston #: M9032A
- CPK #: CPK9032A
- Rod #: 5476
- Pin #: 905-2250-19CP3C
- Locks #: 905X073 SWL
- Rings #: CPN-3937
- Gasket Only #: H30220305
2005-2015 RXP 215/255/260 8.2:1 turbo 100.5mm +.5mm oversize bore x 63.4mm stroke (1508cc) piston kit
- Bore: 100.5mm
- Comp Ratio: 8.2:1
- Piston #: M9041
- CPK #: CPK9041
- Rod #: 5476
- Pin #: 905-2250-19CP3C
- Locks #: 905X073 SWL
- Rings #: CPN-3957
- Gasket Only #: H30220305
2005-2015 RXP 215/255/260 9.5:1 turbo 100.25mm +.25mm oversize bore x 63.4mm stroke (1501cc) piston kit
- Bore: 100.25mm
- Comp Ratio: 9.5:1
- Piston #: M9040
- CPK #: CPK9040
- Rod #: 5476
- Pin #: 905-2250-19CP3C
- Locks #: 905X073 SWL
- Rings #: SWF-20064-3
- Gasket Only #: H30220305
2005-2015 RXP 215/255/260 9.5:1 turbo 100mm std bore x 63.4mm stroke (1494cc) piston kit
- Bore: 100mm
- Comp Ratio: 9.5:1
- Piston #: M9039A
- CPK #: CPK9039A
- Rod #: 5476
- Pin #: 905-2250-19CP3C
- Locks #: 905X073 SWL
- Rings #: CPN-3937
- Gasket Only #: H30220305
2005-2015 RXP 215/255/260 8.4:1 turbo 100.25mm +.25mm oversize bore x 63.4mm stroke (1501cc) piston kit
- Bore: 100.25mm
- Comp Ratio: 8.4:1
- Piston #: M9033
- CPK #: CPK9033
- Rod #: 5476
- Pin #: 905-2250-19CP3C
- Locks #: 905X073 SWL
- Rings #: SWF-20064-3
- Gasket Only #: H30220305
2005-2015 RXP 215/255/260 9.5:1 turbo, 100.5mm +.5mm oversize bore x 63.4mm stroke (1508cc) piston kit
- Bore: 100.5mm
- Comp Ratio: 9.5:1
- Piston #: M9042
- CPK #: CPK9042
- Rod #: 5476
- Pin #: 905-2250-19CP3C
- Locks #: 905X073 SWL
- Rings #: CPN-3957
- Gasket Only #: H30220305
2005-2015 RXP 215/255/260 8.2:1 turbo 100.5mm +.5mm oversize bore x 63.4mm stroke (1508cc) piston kit
- Bore: 100.5mm
- Comp Ratio: 8.2:1
- Piston #: M9041
- CPK #: CPK9041
- Rod #: 5476
- Pin #: 905-2250-19CP3C
- Locks #: 905X073 SWL
- Rings #: CPN-3957
- Gasket Only #: H30220305
2005-2015 RXP 215/255/260 8.4:1 turbo 100mm std bore x 63.4mm stroke (1494cc) piston kit
- Bore: 100mm
- Comp Ratio: 8.4:1
- Piston #: M9032A
- CPK #: CPK9032A
- Rod #: 5476
- Pin #: 905-2250-19CP3C
- Locks #: 905X073 SWL
- Rings #: CPN-3937
- Gasket Only #: H30220305
2005-2015 RXP 215/255/260 9.5:1 turbo 100.25mm +.25mm oversize bore x 63.4mm stroke (1501cc) piston kit
- Bore: 100.25mm
- Comp Ratio: 9.5:1
- Piston #: M9040
- CPK #: CPK9040
- Rod #: 5476
- Pin #: 905-2250-19CP3C
- Locks #: 905X073 SWL
- Rings #: SWF-20064-3
- Gasket Only #: H30220305
2005-2015 RXP 215/255/260 9.5:1 turbo 100mm std bore x 63.4mm stroke (1494cc) piston kit
- Bore: 100mm
- Comp Ratio: 9.5:1
- Piston #: M9039A
- CPK #: CPK9039A
- Rod #: 5476
- Pin #: 905-2250-19CP3C
- Locks #: 905X073 SWL
- Rings #: CPN-3937
- Gasket Only #: H30220305
2005-2015 RXP 215/255/260 8.4:1 turbo 100.25mm +.25mm oversize bore x 63.4mm stroke (1501cc) piston kit
- Bore: 100.25mm
- Comp Ratio: 8.4:1
- Piston #: M9033
- CPK #: CPK9033
- Rod #: 5476
- Pin #: 905-2250-19CP3C
- Locks #: 905X073 SWL
- Rings #: SWF-20064-3
- Gasket Only #: H30220305
2005-2015 RXP 215/255/260 8.4:1 turbo 100mm std bore x 63.4mm stroke (1494cc) piston kit
- Bore: 100mm
- Comp Ratio: 8.4:1
- Piston #: M9032A
- CPK #: CPK9032A
- Rod #: 5476
- Pin #: 905-2250-19CP3C
- Locks #: 905X073 SWL
- Rings #: CPN-3937
- Gasket Only #: H30220305
2005-2015 RXP 215/255/260 9.5:1 turbo, 100.5mm +.5mm oversize bore x 63.4mm stroke (1508cc) piston kit
- Bore: 100.5mm
- Comp Ratio: 9.5:1
- Piston #: M9042
- CPK #: CPK9042
- Rod #: 5476
- Pin #: 905-2250-19CP3C
- Locks #: 905X073 SWL
- Rings #: CPN-3957
- Gasket Only #: H30220305
2005-2015 RXP 215/255/260 8.2:1 turbo 100.5mm +.5mm oversize bore x 63.4mm stroke (1508cc) piston kit
- Bore: 100.5mm
- Comp Ratio: 8.2:1
- Piston #: M9041
- CPK #: CPK9041
- Rod #: 5476
- Pin #: 905-2250-19CP3C
- Locks #: 905X073 SWL
- Rings #: CPN-3957
- Gasket Only #: H30220305
2005-2015 RXP 215/255/260 9.5:1 turbo 100.25mm +.25mm oversize bore x 63.4mm stroke (1501cc) piston kit
- Bore: 100.25mm
- Comp Ratio: 9.5:1
- Piston #: M9040
- CPK #: CPK9040
- Rod #: 5476
- Pin #: 905-2250-19CP3C
- Locks #: 905X073 SWL
- Rings #: SWF-20064-3
- Gasket Only #: H30220305
2005-2015 RXP 215/255/260 9.5:1 turbo 100mm std bore x 63.4mm stroke (1494cc) piston kit
- Bore: 100mm
- Comp Ratio: 9.5:1
- Piston #: M9039A
- CPK #: CPK9039A
- Rod #: 5476
- Pin #: 905-2250-19CP3C
- Locks #: 905X073 SWL
- Rings #: CPN-3937
- Gasket Only #: H30220305
2005-2015 RXP 215/255/260 8.4:1 turbo 100.25mm +.25mm oversize bore x 63.4mm stroke (1501cc) piston kit
- Bore: 100.25mm
- Comp Ratio: 8.4:1
- Piston #: M9033
- CPK #: CPK9033
- Rod #: 5476
- Pin #: 905-2250-19CP3C
- Locks #: 905X073 SWL
- Rings #: SWF-20064-3
- Gasket Only #: H30220305
2006-2010 KTM 250 SX-F 13.5:1 76mm std bore x 54.8mm stroke (248.6cc) piston kit
- Bore: 76mm
- Comp Ratio: 13.5:1
- Piston #: M9003C
- CPK #: CPK9003C
- Rod #: 5415
- Pin #: S630-1650-13C
- Locks #: 630x050 SWL
- Rings #: CP7600C
- Gasket Only #: C3164-HB
2006-2010 KTM 250 SX-F 13.5:1 79mm+3mm oversize bore x 54.8mm stroke (270cc) piston kit
- Bore: 79mm
- Comp Ratio: 13.5:1
- Piston #: MX9031C
- CPK #: CPKX9031C
- Rod #: 5415
- Pin #: S630-1650-13C
- Locks #: 630x050 SWL
- Rings #: CP7900C
- Gasket Only #: C3184
2006-2010 KTM 250 SX-F 13.5:1 76mm std bore x 54.8mm stroke (249cc) piston kit
- Bore: 76mm
- Comp Ratio: 13.5:1
- Piston #: MX9003C
- CPK #: CPKX9003C
- Rod #: 5415
- Pin #: S630-1650-13C
- Locks #: 630x050 SWL
- Rings #: CP7600C
- Gasket Only #: C3164-HB
2006-2011 Kawasaki ZX14 13.25:1 86mm +2mm oversize bore x 66mm stroke (1418cc) nitrous 150 shot piston kit
- Bore: 86mm
- Comp Ratio: 15.5:1
- Piston #: M4135 ***
- CPK #: Call
- Rod #: 5412
- Pin #: W787-2000-15CP1C
- Locks #: 787x050 SWL
- Rings #: CPN-3308
- Gasket Only #: Call
2006-2011 Kawasaki ZX14 14.0:1 87mm +3mm oversize bore x 61mm stroke (1450cc) piston kit
- Bore: 87mm
- Comp Ratio: 15.7:1
- Piston #: M4137
- CPK #: Call
- Rod #: 5412
- Pin #: W787-2000-15CP1C
- Locks #: 787x050 SWL
- Rings #: CPNG-2-3425
- Gasket Only #: Call
2006-2011 Kawasaki ZX14 14.0:1 87mm +3mm oversize bore x 61mm stroke (1450cc) piston kit
- Bore: 87mm
- Comp Ratio: 14.0:1
- Piston #: M4038
- CPK #: Call
- Rod #: 5412
- Pin #: 787-2000-12CP1C
- Locks #: 787x050 SWL
- Rings #: CPN-3425
- Gasket Only #: Call
