2009-2014 Yamaha R1 13.5:1 78mm std bore x 52.2mm stroke (998cc) piston kit
- Bore: 78mm
- Comp Ratio: 13.5:1
- Piston #: M1079C
- CPK #: CPK1079C
- Rod #: 5021
- Pin #: W669-1650-12CP1C
- Locks #: 669x050 SWL
- Rings #: N/A
- Gasket Only #: C8794
2009-2014 Yamaha R1 13:1 80mm +2mm oversize bore x 52.2mm stroke (1050c) piston kit
- Bore: 80mm
- Comp Ratio: 13.0:1
- Piston #: M1080C
- CPK #: CPK1080C
- Rod #: 5021
- Pin #: W669-1650-12CP1C
- Locks #: 669x050 SWL
- Rings #: CPXG8000C (CP8000C Top and Oil) (XG 3149 second ring)
- Gasket Only #: C8794
2009-2014 Yamaha R1 13.5:1 78mm std bore x 52.2mm stroke (998cc) piston kit
- Bore: 77mm
- Comp Ratio: 12.8:1
- Piston #: MX4044C *
- CPK #: CPKX4044C
- Rod #: 4719
- Pin #: W630-1650-13CP1C
- Locks #: 630X050 SWL
- Rings #: CP7700C
- Gasket Only #: C8602-27
2009-2016 Honda CRF450R 12.5:1 96mm std bore x 62.1mm stroke (449cc) piston kit
- Bore: 96mm
- Comp Ratio: 12.5:1
- Piston #: M2057
- CPK #: CPK2057
- Rod #: 8805
- Pin #: W748-2000-15CP1C
- Locks #: 748x050 SWL
- Rings #: CPN2-2-3779
- Gasket Only #: C3270
2009-2016 Honda CRF450R 13.0:1 96mm std bore x 62.1mm stroke (449cc) piston kit
- Bore: 96mm
- Comp Ratio: 13.0:1
- Piston #: M2058
- CPK #: CPK2058
- Rod #: 8805
- Pin #: W748-2000-15CP1C
- Locks #: 748x050 SWL
- Rings #: CPN2-2-3779
- Gasket Only #: C3270
2009-2016 Honda CRF450R 13.0:1 98mm +2mm oversize bore x 62.1mm stroke (468cc) piston kit
- Bore: 98mm
- Comp Ratio: 13.0:1
- Piston #: M2069
- CPK #: CPK2069
- Rod #: 8805
- Pin #: W748-2000-15CP1C
- Locks #: 748x050 SWL
- Rings #: CPN2-3858
- Gasket Only #: C3275
2009-2016 Honda CRF450R 12.5:1 96mm std bore x 62.1mm stroke (449cc) piston kit
- Bore: 96mm
- Comp Ratio: 12.5:1
- Piston #: MX2057
- CPK #: CPKX2057
- Rod #: 8805
- Pin #: S748-2000-15C
- Locks #: 748x050 SWL
- Rings #: CPN2-2-3779
- Gasket Only #: C3270
2009-2016 Honda CRF450R 13.0:1 96mm std bore x 62.1mm stroke (449cc) piston kit
- Bore: 96mm
- Comp Ratio: 13.0:1
- Piston #: MX2058
- CPK #: CPKX2058
- Rod #: 8805
- Pin #: S748-2000-15C
- Locks #: 748x050 SWL
- Rings #: CPN2-2-3779
- Gasket Only #: C3270
2009-2016 Honda CRF450R 13.5:1 96mm std bore x 62.1mm stroke (449cc) piston kit
- Bore: 96mm
- Comp Ratio: 13.5:1
- Piston #: MX2059
- CPK #: CPKX2059
- Rod #: 8805
- Pin #: S748-2000-15C
- Locks #: 748x050 SWL
- Rings #: CPN2-2-3779
- Gasket Only #: C3270
2009 - 2016 Honda CRF450R 13.5:1 , 96mm std bore x 62.1mm stroke Project X Pro Race Profiled Pin Bore (449cc) Pisotn Kit
- Bore: 96mm
- Comp Ratio: 13.5:1
- Piston #: MX2059-P
- CPK #: CPKX2059-P
- Rod #: 8805
- Pin #: S748-2000-15C
- Locks #: 748x050 SWL
- Rings #: CP9600C
- Gasket Only #: C3270
2009 - 2016 Honda CRF450R 14.0:1, 96mm std bore x 62.1mm stroke (449cc), Piston Kit
- Bore: 96mm
- Comp Ratio: 14.0:1
- Piston #: MX2063
- CPK #: CPKX2063
- Rod #: 8805
- Pin #: S748-2000-15C
- Locks #: 748x050 SWL
- Rings #: CPN2-2-3779
- Gasket Only #: C3270
2009-2016 Honda CRF450R 14.0:1 96mm std bore x 62.1mm stroke platinum series1mm smaller pin/ .5mm longer rod (449cc) piston kit
- Bore: 96mm
- Comp Ratio: 14.0:1
- Piston #: MX2P63
- CPK #: CPKX2P63
- Rod #: 8819
- Pin #: S708-2000-15C
- Locks #: 708x050 SWL
- Rings #: CPN2-2-3779
- Gasket Only #: C3270-EST
2009-2018 Kawasaki KX 450F 13.0:1 96mm std bore x 62.1mm stroke (449cc) piston kit
- Bore: 96mm
- Comp Ratio: 13.0:1
- Piston #: M3035
- CPK #: 2009-2015 CPK3035 2016-2017 CPK3135
- Rod #: 8960
- Pin #: W748-2000-15CP1C
- Locks #: 748x050 SWL
- Rings #: CPN2-2-3779
- Gasket Only #: 2009-2015 C3268-HB 2016-2017 C3598-EST
2009-2018 Kawasaki KX 450F 13.0:1 96mm std bore x 62.1mm stroke, (449c) piston kit
- Bore: 96mm
- Comp Ratio: 13.0:1
- Piston #: MX3035
- CPK #: 2009-2015 CPKX3035 2016-2017 CPKX3135
- Rod #: 8960
- Pin #: S748-2000-15C
- Locks #: 748x050 SWL
- Rings #: CPN2-2-3779
- Gasket Only #: 2009-2015 C3268-HB 2016-2017 C3598-EST
2009-2018 Kawasaki KX 450F 13.5:1 96mm std bore x 62.1mm stroke (449cc) piston kit
- Bore: 96mm
- Comp Ratio: 13.5:1
- Piston #: MX3036
- CPK #: 2009-2015 CPKX3036 2016-2017 CPKX3136
- Rod #: 8960
- Pin #: S748-2000-15C
- Locks #: 748x050 SWL
- Rings #: CPN2-2-3779
- Gasket Only #: 2009-2015 C3268-HB 2016-2017 C3598-EST
2009-2018 Kawasaki KX 450F 13.5:1 96mm std bore x 62.1mm stroke profiled pin bore (449cc) pro race piston kit
- Bore: 96mm
- Comp Ratio: 13.5:1
- Piston #: MX3036-P
- CPK #: 2009-2015 CPKX3036-P 2016-2017 CPKX3136-P
- Rod #: 8960
- Pin #: S748-2000-15C
- Locks #: 748x050 SWL
- Rings #: CP9600C
- Gasket Only #: 2009-2015 C3268-HB 2016-2017 C3598-EST
2009-2018 Kawasaki KX450F 13.5:1 96mm std bore x 62.1mm stroke platinum series1mm smaller pin 3mm longer rod (449cc) piston kit
- Bore: 96mm
- Comp Ratio: 13.5:1
- Piston #: MX3P36
- CPK #: 2009-2015 CPKX3P36 2016-2017 CPKX31P36
- Rod #: 8815
- Pin #: S708-2000-15C
- Locks #: 708x050 SWL
- Rings #: CPN2-2-3779
- Gasket Only #: 2009-2015 C3268-HB 2016-2017 C3598-EST
2009-2018 Kawasaki ZX6R 67mm std bore x 42.5mm stroke (600)cc piston kit
- Bore: 67mm
- Comp Ratio: 13.5:1
- Piston #: M3070
- CPK #: Call
- Rod #: Light 09-12 8841; HD 09-12 10386; Light 13-17 7722; HD 13-17 9661
- Pin #: 591-1500-13CP1C
- Locks #: 591x050 SWL
- Rings #: MAC06700
- Gasket Only #: Call
2009-2018 Kawasaki ZX6R 69mm std bore x 42.5mm stroke (636)cc piston kit
- Bore: 69mm
- Comp Ratio: 13.8:1
- Piston #: M3071
- CPK #: Call
- Rod #: Light 09-12 8841; HD 09-12 10386; Light 13-17 7722; HD 13-17 9661
- Pin #: 591-1500-13CP1C
- Locks #: 591x050 SWL
- Rings #: MAC06900
- Gasket Only #: Call
2009-2019 Polaris RZR 170 62mm +1mm bore x 57.8mm stroke (169cc) piston kit
- Bore: 62mm
- Comp Ratio: 11.0:1
- Piston #: M9029
- CPK #: Call
- Rod #: 10339
- Pin #: 591-1650-11CP1C
- Locks #: 591x050 SWL
- Rings #: N/A
- Gasket Only #: Call
2010-2013 Honda CRF250R 13.5:1 76.8mm std bore x 53.8mm stroke (249cc) piston kit
- Bore: 76.8mm
- Comp Ratio: 13.5:1
- Piston #: M2070C
- CPK #: CPK2070C
- Rod #: 8822
- Pin #: W630-1650-13CP1C
- Locks #: 630x050 SWL
- Rings #: CP7680C
- Gasket Only #: C3288
2010-2013 Honda CRF250R 13.5:1 76.8mm std bore x 53.8mm stroke (249cc) piston kit
- Bore: 76.8mm
- Comp Ratio: 13.5:1
- Piston #: MX2070C
- CPK #: CPKX2070C
- Rod #: 8822
- Pin #: S630-1650-13C
- Locks #: 630x050 SWL
- Rings #: CP7680C
- Gasket Only #: C3288
2010-2013 Honda CRF250R 14.0:1 76.8mm std bore x 53.8mm stroke (249cc) piston kit
- Bore: 76.8mm
- Comp Ratio: 14.0:1
- Piston #: MX2071C
- CPK #: CPKX2071C
- Rod #: 8822
- Pin #: S630-1650-13C
- Locks #: 630x050 SWL
- Rings #: CP7680C
- Gasket Only #: C3288
2010-2013 Honda CRF250R 14.5:1 76.8mm std bore x 53.8mm stroke (249cc) piston kit
- Bore: 76.8mm
- Comp Ratio: 14.5:1
- Piston #: MX2072C
- CPK #: CPKX2072C
- Rod #: 8822
- Pin #: S630-1650-13C
- Locks #: 630x050 SWL
- Rings #: CP7680C
- Gasket Only #: C3288
2010-2013 Honda CRF250R 13.5:1 79 mm +2.2mm oversize bore x 53.8mm stroke (264cc) piston kit
- Bore: 79mm
- Comp Ratio: 13.5:1
- Piston #: MX2073C
- CPK #: CPKX2073C
- Rod #: 8822
- Pin #: S630-1650-13C
- Locks #: 630x050 SWL
- Rings #: CP7900C
- Gasket Only #: C3289
2010-2013 Honda CRF250 14.0:1 76.8mm std bore x 53.8mm stroke platinum series1mm smaller pin/ 2mm longer rod (249cc) piston kit
- Bore: 76.8mm
- Comp Ratio: 14.0:1
- Piston #: MX2P71C
- CPK #: CPKX2P71C
- Rod #: 8821
- Pin #: S591-1650-13C
- Locks #: 591x040 SWL
- Rings #: CP7680C
- Gasket Only #: C3288-EST
2010-2016 Kawasaki KX250F 13.5:1 77mm std bore x 53.6mm stroke (249cc) piston kit
- Bore: 77mm
- Comp Ratio: 13.5:1
- Piston #: MX3050C
- CPK #: CPKX3050C
- Rod #: 8817
- Pin #: S630-1650-13C
- Locks #: 630x050 SWL
- Rings #: CP7700C
- Gasket Only #: C3267-HB
2010-2016 Kawasaki KX250F 14.2:1 77mm std bore x 53.6mm stroke (249cc) piston kit
- Bore: 77mm
- Comp Ratio: 14.2:1
- Piston #: MX3051C
- CPK #: CPKX3051C
- Rod #: 8817
- Pin #: S630-1650-13C
- Locks #: 630x050 SWL
- Rings #: CP7700C
- Gasket Only #: C3267-HB
2010-2016 Kawasaki KX250F 14.0:1 77mm std bore x 53.6mm stroke platinum series 1mm smaller pin 1.5 mm longer rod (249cc) piston kit
- Bore: 77mm
- Comp Ratio: 14.0:1
- Piston #: MX3P51C
- CPK #: CPKX3P51C
- Rod #: 8816
- Pin #: S591-1650-13C
- Locks #: 591x040 SWL
- Rings #: CP7700C
- Gasket Only #: C3267-EST
2010-2016 Kawasaki KX250F 14.0:1 77mm std bore x 53.6mm stroke platinum series 1mm smaller pin1.5mm longer rod profiled pin bore (249cc) pro race piston kit
- Bore: 77mm
- Comp Ratio: 14.0:1
- Piston #: MX3P51C-P
- CPK #: CPKX3P51-P
- Rod #: 8816
- Pin #: S591-1650-13C
- Locks #: 591x040 SWL
- Rings #: CP7700C
- Gasket Only #: C3267-EST
2010-2018 Suzuki RM-Z250 13.5:1 77mm std bore x 53.6mm stroke (249cc) piston kit
- Bore: 77mm
- Comp Ratio: 13.5:1
- Piston #: M3031C
- CPK #: CPK3031C
- Rod #: 8810
- Pin #: W630-1650-13CP1C
- Locks #: 630x050 SWL
- Rings #: CP7700C
- Gasket Only #: C3406
2010-2018 Suzuki RM-Z250 13.5:1 77mm std bore x 53.6mm stroke (249cc) piston kit
- Bore: 77mm
- Comp Ratio: 13.5:1
- Piston #: MX3031C
- CPK #: CPKX3031C
- Rod #: 8810
- Pin #: S630-1650-13C
- Locks #: 630x050 SWL
- Rings #: CP7700C
- Gasket Only #: C3406
2010-2018 Suzuki RM-Z250 14.2:1 77mm std bore x 53.6mm stroke (249cc) piston kit
- Bore: 77mm
- Comp Ratio: 14.2:1
- Piston #: MX3032C
- CPK #: CPKX3032C
- Rod #: 8810
- Pin #: S630-1650-13C
- Locks #: 630x050 SWL
- Rings #: CP7700C
- Gasket Only #: C3406
2010-2018 Suzuki RMZ250 14.2:1 77mm std bore x 53.6mm stroke platinum series 1mm smaller pin/ 1.5mm longer rod, (249cc) piston kit
- Bore: 77mm
- Comp Ratio: 14.2:1
- Piston #: MX3P32C
- CPK #: CPKX3P32C
- Rod #: 9255
- Pin #: S591-1650-13C
- Locks #: 591x040 SWL
- Rings #: CP7700C
- Gasket Only #: C3406-EST
2010-2019 YZ450F 13.0:1 97mm std bore x 60.8mm stroke (449cc), piston kit
- Bore: 97mm
- Comp Ratio: 13.0:1
- Piston #: MX1068
- CPK #: CPKX1068
- Rod #: 8823
- Pin #: S708-2000-15C
- Locks #: 708x050 SWL
- Rings #: CPN2-2-3819
- Gasket Only #: C3395
2010-2019 YZ450F 13.75:1 97mm std bore x 60.8mm stroke (449cc) piston kit
- Bore: 97mm
- Comp Ratio: 13.75:1
- Piston #: MX1069
- CPK #: CPKX1069
- Rod #: 8823
- Pin #: S708-2000-15C
- Locks #: 708x050 SWL
- Rings #: CPN2-2-3819
- Gasket Only #: C3395
2010-2019 YZ450F 13.5:1 97mm std bore x 60.8mm stroke (449cc) piston kit
- Bore: 97mm
- Comp Ratio: 13.5:1
- Piston #: MX1070
- CPK #: CPKX1070
- Rod #: 8823
- Pin #: S708-2000-15C
- Locks #: 708x050 SWL
- Rings #: CPN2-2-3819
- Gasket Only #: C3395
2010-2019 YZ450F 13.5:1 97mm std bore x 60.8mm stroke platinum series std. pin dia/ 2.5mm longer rod (449cc) piston kit
- Bore: 97mm
- Comp Ratio: 13.5:1
- Piston #: MX1P70
- CPK #: CPKX1P70
- Rod #: 9501
- Pin #: S708-2000-15C
- Locks #: 708x050 SWL
- Rings #: CPN2-2-3819
- Gasket Only #: C3395
2011-2012 KTM 250 SX-F 14.0:1 76mm std bore x 54.8mm stroke (249cc) piston kit
- Bore: 76mm
- Comp Ratio: 14.0:1
- Piston #: MX9034C
- CPK #: CPKX9034C
- Rod #: 5415
- Pin #: S630-1650-13C
- Locks #: 630x050 SWL
- Rings #: CP7600C
- Gasket Only #: C3164-HB
2011-2014 Polaris RZR XP900 9.0:1 Turbo 93mm std bore x 64.4mm stroke (875cc) piston kit
- Bore: 93mm
- Comp Ratio: 9.0:1
- Piston #: M9035
- CPK #: CPK9035
- Rod #: 6866
- Pin #: 787-2250-16CP1C
- Locks #: 787x050 SWL
- Rings #: CPN-3661
- Gasket Only #: C3446
2011-2014 Polaris RZR XP900 11.5:1 93mm std bore x 64.4mm stroke (875cc) piston kit
- Bore: 93mm
- Comp Ratio: 11.5:1
- Piston #: M9036
- CPK #: CPK9036
- Rod #: 6866
- Pin #: W787-2000-15CP1C
- Locks #: 787x050 SWL
- Rings #: CPN-3661
- Gasket Only #: C3446
2011-2014 Polaris RZR XP900 12.5:1 93mm std bore x 64.4mm stroke (875cc) piston kit
- Bore: 93mm
- Comp Ratio: 12.5:1
- Piston #: M9037
- CPK #: CPK9037
- Rod #: 6866
- Pin #: W787-2000-15CP1C
- Locks #: 787x050 SWL
- Rings #: CPN-3661
- Gasket Only #: C3446
2011-2014 Polaris RZR XP900 11.5:1 95mm +2mm oversize bore x 64.4mm stroke (912cc) piston Kit
- Bore: 95mm
- Comp Ratio: 11.5:1
- Piston #: M9038
- CPK #: CPK9038
- Rod #: 6866
- Pin #: W787-2000-15CP1C
- Locks #: 787x050 SWL
- Rings #: CPN2-3740
- Gasket Only #: C3447
2011-2014 Polaris RZR XP900 11.5:1 96mm +3mm oversize bore x 64.4mm stroke (932cc) piston kit
- Bore: 96mm
- Comp Ratio: 11.5:1
- Piston #: M9053
- CPK #: CPK9053
- Rod #: 6866
- Pin #: W787-2000-15CP1C
- Locks #: 787x050 SWL
- Rings #: CPN2-3780
- Gasket Only #: C3447
2011-2014 Polaris RZR XP900 11.5:1 98mm +5mm oversize bore x 64.4mm stroke (971cc) piston Kit
- Bore: 98mm
- Comp Ratio: 11.5:1
- Piston #: M9067
- CPK #: CPK9067
- Rod #: 6866
- Pin #: W787-2000-15CP1C
- Locks #: 787x050 SWL
- Rings #: CPN2-3858
- Gasket Only #: Call
2012-13 Polaris RZR570 11.5:1 99mm std bore x 73.6mm stroke (567cc) piston kit
- Bore: 99mm
- Comp Ratio: 11.5:1
- Piston #: M9050
- CPK #: Call
- Rod #: N/A
- Pin #: 866-2000-15CP1C
- Locks #: 866X063 SWL
- Rings #: CPN2-3897
- Gasket Only #: Call
2012-2018 Kawasaki ZX14 14.1:1 84mm std bore x 65mm stroke (1352cc) piston kit
- Bore: 84mm
- Comp Ratio: 14.1:1
- Piston #: M4036
- CPK #: Call
- Rod #: 7291
- Pin #: 787-2000-12CP1C
- Locks #: 787x050 SWL
- Rings #: CPN-3307
- Gasket Only #: Call
2012-2018 Kawasaki ZX14 14.1:1 86mm +2mm oversize bore x 65mm stroke (1418cc) piston kit
- Bore: 86mm
- Comp Ratio: 14.1:1
- Piston #: M4037
- CPK #: Call
- Rod #: 7291
- Pin #: 787-2000-12CP1C
- Locks #: 787x050 SWL
- Rings #: CPN-3386
- Gasket Only #: Call
2012-2018 Kawasaki ZX14 9.5:1 Turbo 84mm std bore x 65mm stroke (1352cc) piston kit
- Bore: 84mm
- Comp Ratio: 9.5:1
- Piston #: M4048
- CPK #: Call
- Rod #: 7291
- Pin #: 787-2000-12CP1C
- Locks #: 787x050 SWL
- Rings #: CPN-3307
- Gasket Only #: Call
2012-2018 Kawasaki ZX14 16.1:1 86mm +2mm oversize bore x 65mm stroke (1418cc) piston kit
- Bore: 86mm
- Comp Ratio: 16.1:1
- Piston #: M4136
- CPK #: Call
- Rod #: 7291
- Pin #: W787-2000-15CP1C
- Locks #: 787x050 SWL
- Rings #: CPN-3308
- Gasket Only #: Call
2012-2018 Kawasaki ZX14 14.0:1 87mm +3mm oversize bore x 65mm stroke (1450cc) piston kit
- Bore: 87mm
- Comp Ratio: 16.3:1
- Piston #: M4137
- CPK #: Call
- Rod #: 7291
- Pin #: W787-2000-15CP1C
- Locks #: 787x050 SWL
- Rings #: CPNG-2-3425
- Gasket Only #: Call
2012-2018 Kawasaki ZX14 16.1:1 86mm +2mm oversize bore x 70mm stroke (1418cc) nitrous 150 shot piston kit
- Bore: 86mm
- Comp Ratio: 16.1:1
- Piston #: M4135 * & ***
- CPK #: Call
- Rod #: 7291
- Pin #: W787-2000-15CP1C
- Locks #: 787x050 SWL
- Rings #: CPN-3308
- Gasket Only #: Call
2013-2015 Husqvarna FC 250 14.7:1 78mm std bore x 52.3mm stroke (249.91cc) piston kit
- Bore: 78mm
- Comp Ratio: 14.7:1
- Piston #: MX9046C
- CPK #: CPKX9046C
- Rod #: N/A
- Pin #: S630-1650-13C
- Locks #: 630x050 SWL
- Rings #: CP7800C
- Gasket Only #: C3511
2013-2015 KTM 250SX-F 14.7:1 78mm std bore x 52.3mm stroke (249.91cc) piston kit
- Bore: 78mm
- Comp Ratio: 14.7:1
- Piston #: MX9046C
- CPK #: CPKX9046C
- Rod #: N/A
- Pin #: S630-1650-13C
- Locks #: 630x050 SWL
- Rings #: CP7800C
- Gasket Only #: C3511
2013-15 KTM SX-F 13.0:1 95mm std bore x 63.4mm stroke (449.3cc) piston kit
- Bore: 95mm
- Comp Ratio: 13.0:1
- Piston #: MX9045
- CPK #: CPKX9045
- Rod #: N/A
- Pin #: S748-2000-15C
- Locks #: 748x050 SWL
- Rings #: CPN2-2-3740
- Gasket Only #: C3241
2014-2015 Can-Am Commander 12.0:1 91mm std bore x 75mm stroke (976cc) piston kit
- Bore: 91mm
- Comp Ratio: 12.0:1
- Piston #: M9059
- CPK #: Call
- Rod #: 8155
- Pin #: 866-2250-15CP1C
- Locks #: 866X063 SWL
- Rings #: CPN-3583
- Gasket Only #: Call
2014-2015 Can-Am Maverick 12.0:1 91mm std bore x 75mm stroke (976cc) piston kit
- Bore: 91mm
- Comp Ratio: 12.0:1
- Piston #: M9058
- CPK #: Call
- Rod #: 8155
- Pin #: 866-2250-15CP1C
- Locks #: 866X063 SWL
- Rings #: CPN-3583
- Gasket Only #: Call
2014-2015 Honda CRF250R 14.0:1 76.8mm std bore x 53.8mm stroke (249cc) piston kit
- Bore: 76.8mm
- Comp Ratio: 14.0:1
- Piston #: MX2171C
- CPK #: CPKX2171C
- Rod #: 8822
- Pin #: S630-1650-13C
- Locks #: 630x050 SWL
- Rings #: CP7680C
- Gasket Only #: C3288
2014-15 Honda CRF250R 14.5:1 76.8mm std bore x 53.8mm stroke (249cc) piston kit
- Bore: 76.8mm
- Comp Ratio: 14.5:1
- Piston #: MX2172C
- CPK #: CPKX2172C
- Rod #: 8822
- Pin #: S630-1650-13C
- Locks #: 630x050 SWL
- Rings #: CP7680C
- Gasket Only #: C3288
2014-15 Honda CRF250 14.0:1 76.8mm Std Bore x 53.8mm stroke platinum series 1mm smaller pin/ 2mm longer rod (249cc) piston kit
- Bore: 76.8mm
- Comp Ratio: 14.0:1
- Piston #: MX2P72C
- CPK #: CPKX2P72C
- Rod #: 8821
- Pin #: S591-1650-13C
- Locks #: 591x040 SWL
- Rings #: CP7680C
- Gasket Only #: C3288
